Products > Optical Lenses
We have been working hard to constantly promote process improvement and technological innovation. And we always committed to provide high-quality products.
1
Total:1 page, with 8 products
Double-convex lens
Parameter List:
Material：
K9,BK7,Fused Silica,Caf2,MgF2,...
Diameter:
1/12.7/25.4/Customized
Dia Tolerance:
±0.01/±0.05/±0.1*/Customized
Center Thickness:
0.1/0.2/0.5/Customized
Edge Thickness:
0.1/0.2/0.5/Customized
Focal Length:
12.5/25.4/50.8/100/Customized
Centering:
±3arcmin/Customized
Surface Quality:
10/5,20/10,40/20,60/40
Clear Aperture:
＞90%
Coating:
AR/BBAR@any wavelength range
Bevel:
Protective bevel as needed
Surface Accuracy:
1/10,1/8,1/4,1/2λ
Applications: Camera lenses, telescopes, microscopes, laser focusing systems, projectors, etc.
Coatings: Typically feature anti-reflection coatings; specialized ...
Plano-convex lens
Parameter List:
Material：
K9,BK7,Fused Silica,Caf2,MgF2,...
Diameter:
1/12.7/25.4/Customized
Dia Tolerance:
±0.01/±0.05/±0.1*/Customized
Center Thickness:
0.1/0.2/0.5/Customized
Edge Thickness:
0.1/0.2/0.5/Customized
Focal Length:
12.5/25.4/50.8/100/Customized
Centering:
±3arcmin/Customized
Surface Quality:
10/5,20/10,40/20,60/40
Clear Aperture:
＞90%
Coating:
AR/BBAR@any wavelength range
Bevel:
Protective bevel as needed
Surface Accuracy:
1/10,1/8,1/4,1/2λ
Ap ...
Double-concave lens
Parameter List:
Material ：
K9,BK7,Fused Silica,Caf2,MgF2,...
Diameter:
1/12.7/25.4/Customized
Dia Tolerance:
±0.01/±0.05/±0.1*/Customized
Center Thickness:
0.1/0.2/0.5/Customized
Edge Thickness:
0.1/0.2/0.5/Customized
Focal Length:
12.5/25.4/50.8/100/Customized
Centering:
±3arcmin/Customized
Surface Quality:
10/5,20/10,40/20,60/40
Clear Aperture:
＞ 90%
Coating:
AR/BBAR@any wavelength range
Bevel:
Protective bevel as needed
Surface Accuracy:
1/10,1/8,1/4,1/2λ
...
